Shike（LEGACY）EVseriesLithium battery is a battery pack specially used for mobile mechanical fast charging. It adopts internationally advanced lithium iron phosphate (fifep04) material cell. High energy density; Ultra long cycle life; Strong stability; It supports the excellent characteristics of high-power charge and discharge and is a new generation of stable; Safety; Reliable green power energy.
Product features
EV series battery adopts the battery management system (BMS) independently developed by Shike team, which is specially designed for mobile machinery. Overtemperature; Overcurrent; Overvoltage protection, original power analog output (A0), power digital output (D0), 485 communication / can communication and other functions. Meet various scenarios of mobile machinery.
Product advantages
Excellent battery protection (over temperature, over voltage, over current, short circuit, etc.)
Provide analog (A0) output and SOC analog output of 0-5V, which can obtain real-time power information
Provide digital output (D0) output to inform the power status according to the demand
Charge / discharge ports, charge ports and discharge ports do not interfere with each other
Panel LED power display; System status display
Support RS485 communication / can communication
Professional industrial design and material selection, which can be applied to various complex application scenarios
It supports 2C charging and 1C discharging to meet the requirements of rapid power replenishment of equipment
Wide temperature working environment conditions, - 10 ℃ - 60 ℃
Small size
Support customization
Product specification

model	Standard voltage（V）	Standard capacity（AH）	Monomer weight（KG）	Box size
				(L*W*H) mm
EV24-30	25.6	30	9	390*199*130
EV24-40 (1.0edition)		40	17.5	315*237*165
EV24-40 (2.0edition)		40	17.5	527*155*170
EV24-60 (1.0edition)		60	25	333*241*214
EV24-60 (2.0edition)		60	25	325*237*187
EV24-60 (3.0edition)		60	25	433*220*150
EV24-60 (4.0edition)		60	25	383*200*193
EV24-80/100		80/100	29/34	356*335*216
EV24-120		120	41.5	400*285*248
EV24-160/200		160/200	60/65	551*210*433
Charging voltage(V)	29.2
Maximum battery voltage(V)	29.2
Minimum discharge voltage(V)	21.6
Nominal discharge current	0.5C Continuous current discharge。
Nominal charge current	1C current continuous charging: maximum 2C charging, continuous charging time over 1C charging is less than 10min
Charging protection	When the maximum monomer voltage is higher than 3.7V, the charging is automatically cut off
Discharge protection	If the minimum single string voltage is lower than 2.7V, the discharge will be cut off automatically.
Over temperature protection	When the internal temperature of the battery is higher than 65 ℃, the charging / discharging is automatically cut off.
Short circuit protection	Quick fuse included
SOC (surplus Electric quantity)	Real time feedback of battery power status.
surplus Electric quantityLEDdisplay	5 grid green light shows 0% - 100% of power,
Alarm LED lamp	Red light, flashing indicates abnormal battery alarm.
RS 485ignal communication	RS 485 is used to communicate with the host or connect with other modules.
DI input	Remote battery switch control.
DO output	Two dry contact DO outputs.
AO output	Analog output 0V ~ 5V, corresponding to SOC 0% ~ 100%,
working temperature	-10℃~60℃
Storage temperature	0℃~40℃
Working humidity	Relative humidity 10% ~ 80%, no condensation.
Cooling system	Natural cooling.

model	Standard voltage（V）	Standard capacity（AH）	Monomer weight（KG）	Box size
				(L*W*H) mm
EV48-20	48V	20	17.5	315*237*165
EV48-30		30	21.4	380*238*202
EV48 -40/60 1.0edition		40/60	32/40	567*241*226
EV48 -40/60 2.0edition		40/60	32/40	430*350*240
EV48-40 3.0edition		40	32	356*335*216
EV48-50		50	36	788*170*170
EV48-80/100		80/100	48/65	614*346*202
EV48-160		160	86.5	606*456*255
EV48- 180		180	95	600*275*517
EV48-200		200	130	700*555*294
Charging voltage(V)	54.7
Maximum battery voltage(V)	54.7
Minimum discharge voltage(V)	40.5
Nominal discharge current	Continuous discharge at 0.5c current.
Nominal charging current	1C current continuous charging: maximum 2C charging, continuous charging time over 1C charging is less than 10min
Charging protection	When the maximum monomer voltage is higher than 3.7V, the charging is automatically cut off.
Discharge protection	If the minimum single string voltage is lower than 2.7V, the discharge will be cut off automatically.
Over temperature protection	If the internal temperature of the battery is higher than 65C, the charge / discharge will be cut off automatically.
Short circuit protection	Quick fuse included
SOC(surplus Electric quantity)	Real time feedback of battery power status.
surplus Electric quantity LED display	5 gridGreen light displayElectric quantity0% -100%。
call the police LED lamp	Red light, flashing indicates abnormal battery alarm,
RS -485communication	RS-485 is used to communicate with the host or connect with other modules.
DI input	Remote battery switch control.
DO output	Two dry contact DO outputs.
AO output	Analog output 0V ~ 5V, corresponding to s0c0% ~ 100%.
working temperature	-10℃≈60℃
Storage temperature	0℃~40℃
Working humidity	Relative humidity 10% ~ 80%, no condensation.
Cooling system	Natural cooling.
